SERIES 8201K

N.C. 2/2 WAYS SERVICEABLE SOLENOID VALVES INOX -30 mm d.n. Ø14

SERIES 8201K N.C. 2/2 WAYS SERVICEABLE SOLENOID VALVES INOX  -30 mm d.n. Ø14
STAINLESS STEEL

Category: DIRECT ACTION SOLENOID VALVES

Ways: 2/2

Surface treatments applicable: no

Notes: 0

The solenoid valves of the 8201K series are 2/2 ways, normally closed, serviceable, they are completely in AISI 316 stainless steel, with 30 mm coil d.n. Ø14
  • Direct action (minimum pressure not required)
  • Professional applications
  • Suitable to be cleaned inside
  • DN insert made of stainless steel for the maximum resistance
  • 30 mm Ø14 coil
Air, water, steam, industrial automation, car washes, compressors, industrial washing, food & beverage. Other fluids after checking compatibility.
The main construction components of the solenoid valves of the 8251 series are:
  • EN12165-CW617N forged brass body
  • AISI 304L stainless steel welded to the fixed core
  • AISI 303 stainless steel DN insert
  • AISI 430F stainless steel cores
  • AISI 302 stainless steel spring
  • Sealing gaskets: EPDM, FKM  for food contact, FKM PLUS for food contact
  • 30 mm H class coill
8000BH
8000BH
7000-CON
7000-CON
models
8201-k-00
8201-k-00
8201-k-01
8201-k-01
8201-k-02
8201-k-02
8201-k-03
8201-k-03
8960
8960
