![SERIES F100/B [FKM] X-TREME PLUS](https://www.olab.it/immaginiProdotti/foto-principale/f100xx fkm x-treme plus-23c830.png)
Category: BRASS FITTINGS
Notes:
The F100/B
Series – X-TREME PLUS is a high?performance solution for fast and secure
connections of plastic tubing in low?pressure car wash systems, where perfect
sealing, durability, and chemical resistance are critical.
Each fitting
features a metal release clamp in nickel?plated brass and an OLAB-certified
FKM O-Ring, ideal for contact with detergents, solvents, and hot water up
to +160°C (+320°F).
The nickel?plated
OT58 brass body, stainless?steel retaining washer, and fully
serviceable structure ensure maximum corrosion resistance and long?term
integrity. The compact size and high?efficiency clamping system
allow easy installation even in tight configurations, with full compatibility
for calibrated tubing made of PA6, PA11, PA12, PTFE, FEP, polyethylene, and
polyurethane.
The product
line includes ISO 228 BSP cylindrical and ISO 7 BSPT tapered threads,
in G1/8, G1/4, G3/8, G1/2 and R1/8, R1/4, R3/8, R1/2, ensuring
broad integration with any manifold or connection setup. The maximum
operating pressure (PS) is 20 bar (290 psi), with a temperature
service range (TS) from –15°C to +160°C (+5°F to +320°F), subject to
the tubing specifications.
Every
F100/B fitting is 100% leak?tested and CE certified, ensuring
full compliance with European safety and reliability standards for professional
use.
Technical features:
FORGED AND MACHINED FROM BAR FOR SUPERIOR MATERIAL QUALITY
Made from high-quality nickel-plated OT58 brass, these fittings offer outstanding structural consistency and long-term reliability.
BUILT TO LAST EVEN IN DEMANDING CONDITIONS
Robust design and high-performance FKM gaskets ensure reliable operation in moisture, detergents, or heavy-duty cycles.
OLAB-CERTIFIED FKM SEALING GASKETS
FKM O-Rings guarantee excellent chemical resistance, maintaining integrity up to +160°C (+320°F) and in low temperatures.
100% PRODUCTION TESTED FOR LEAK-FREE OPERATION
Each fitting is individually tested to ensure tight sealing and absolute system safety.
MAXIMUM CORROSION RESISTANCE IN CAR WASH ENVIRONMENTS
Nickel-plated brass body and clamp, combined with stainless-steel grip washer, offer superior corrosion protection.
FULL RANGE AVAILABLE FOR EVERY CONNECTION NEED
Offered in multiple sizes and thread standards (ISO 228 BSP and ISO 7 BSPT), for compatibility with any setup.
SECURE TUBE RELEASE THANKS TO METAL CLAMPING SYSTEM
Tube engagement and release remain efficient and smooth over time, even under intensive use.
COMPACT DESIGN FOR SPACE?CONSTRAINED INSTALLATIONS
Minimal footprint allows for easy integration in tight spaces and multi-port manifolds.
