SERIES F100/B [NBR]

PUSH-IN FITTINGS FOR PLASTIC PIPES WITH METAL SLEEVE-NBR

SERIES F100/B [NBR] PUSH-IN FITTINGS FOR PLASTIC PIPES WITH METAL SLEEVE-NBR

Category: BRASS FITTINGS

Acceptance of the Treaty Personal data
download pdf
Description

PUSH-IN FITTINGS FOR PLASTIC PIPES WITH METAL RELEASE SLEEVE + O.R. NBR
BODY: NICKEL-PLATED BRASS (OT58)
GASKET: NBR
STAINLESS STEEL LOCKING RING
NICKEL PLATED BRASS (OT58) RELEASE PLIERS
DESIGNED FOR PROFESSIONAL AIR SYSTEMS
PS: 20 BAR (check the technical data sheet of the pipe you want to use)
TS: -20 ÷ +80 °C

Main features

  • Safe and reliable
  • rugged (brass release pliers)
  • Extremely efficient tube release thanks to the brass clamp
  • NBR seal
  • Cylindrical gas threads ISO 228 (BSP); conical gas ISO 7 (BSPT)
  • Connecting pipes PA6, PA11, PA12, PTFE, FEP, Polyethylene, Polyurethane (with calibrated diameter)
  • Temperature: (check the technical data sheet of the tube you want to use)
    • FKM -15°C ÷ +160°C (check the technical data sheet of the tube you want to use)
    • NBR -20 °C ÷ + 80°C  (check the technical data sheet of the tube you want to use)
  • Max pressure 20 bar (check the technical data sheet of the pipe you want to use)

Applications

Fluids : air

Components

The main construction components of the fittings of the F100/B series are:

  • Nickel-plated brass body
  • Nickel-plated brass release sleeve
  • Stainless steel locking ring
  • Sealing gasket (O-ring) made of NBR

Description Main features Applications Components

PUSH-IN FITTINGS FOR PLASTIC PIPES WITH METAL RELEASE SLEEVE + O.R. NBR
BODY: NICKEL-PLATED BRASS (OT58)
GASKET: NBR
STAINLESS STEEL LOCKING RING
NICKEL PLATED BRASS (OT58) RELEASE PLIERS
DESIGNED FOR PROFESSIONAL AIR SYSTEMS
PS: 20 BAR (check the technical data sheet of the pipe you want to use)
TS: -20 ÷ +80 °C

  • Safe and reliable
  • rugged (brass release pliers)
  • Extremely efficient tube release thanks to the brass clamp
  • NBR seal
  • Cylindrical gas threads ISO 228 (BSP); conical gas ISO 7 (BSPT)
  • Connecting pipes PA6, PA11, PA12, PTFE, FEP, Polyethylene, Polyurethane (with calibrated diameter)
  • Temperature: (check the technical data sheet of the tube you want to use)
    • FKM -15°C ÷ +160°C (check the technical data sheet of the tube you want to use)
    • NBR -20 °C ÷ + 80°C  (check the technical data sheet of the tube you want to use)
  • Max pressure 20 bar (check the technical data sheet of the pipe you want to use)

Fluids : air

The main construction components of the fittings of the F100/B series are:

  • Nickel-plated brass body
  • Nickel-plated brass release sleeve
  • Stainless steel locking ring
  • Sealing gasket (O-ring) made of NBR
