Category: STAINLESS STEEL FITTINGS
Notes:
The Series
04500 – X-TREME PRO fittings are engineered specifically for high-pressure
car wash systems, where mechanical strength, structural integrity, and
long-term reliability are critical.
Manufactured entirely from AISI 316L
stainless steel, each component is hot forged or machined from solid bar
stock to eliminate porosity, cracks, or internal defects that may compromise
performance.
Thanks to pressure-calibrated
wall thicknesses, these fittings can withstand up to 130 bar (1885 psi)
while ensuring perfect hydraulic sealing, even under harsh and
high-cycle conditions.
Their exceptional corrosion resistance makes them
ideal for chemically aggressive environments, including those with heavy-duty
detergents.
They are
available in both ISO 228 cylindrical gas threads (BSP) and ISO 7
tapered gas threads (BSPT), covering a complete range from G1/8 to
R2. The operating temperature range extends from –50°C to
+220°C (–58°F to +428°F), maintaining consistent performance over time.
Fully compliant with European standards, these fittings are CE
certified to guarantee safety, pressure resistance, and long-term
industrial reliability in demanding installations.
Technical features:
HOT-FORGED AND MACHINED FROM SOLID BAR FOR SUPERIOR QUALITY
Each fitting is made from full solid bar or hot-forged stainless steel to eliminate internal defects, cracks or porosity.
SPECIFIC WALL THICKNESS FOR HIGH?PRESSURE APPLICATIONS
The dimensions are engineered to ensure the exact wall thickness required to withstand up to 130 bar (1885 psi).
BUILT TO LAST UNDER EXTREME CONDITIONS
Designed for demanding environments with frequent wash cycles, these fittings maintain structural integrity under high pressure.
EXCELLENT CORROSION RESISTANCE
Made entirely from AISI 316L stainless steel, they are ideal for use with corrosive fluids and harsh external conditions.
LEAK?FREE PRECISION THREADING
CNC-machined threads ensure a perfect seal with no risk of leakage, reducing the need for additional sealing materials.
FULL RANGE AVAILABLE TO MATCH ANY INSTALLATION NEED
Available in all major BSP and BSPT gas thread sizes, both cylindrical and tapered, from G1/8 to R2.
