SERIES 11000

• SAFE SEALING: double O-ring seal on the tube that guarantees perfect sealing of the device from the environment BALANCED FLOW RATE OF BLOCKS: the flow rate of each pilot-operated solenoid pilot i
• 100% tested to guarantee a perfect balance
• Double locking thread on the blocks
• Coil insulation guaranteed by the top and bottom O-ring seals

The solenoid valves of 11000 series are designed to be installed on small refrigeration and air-conditioning system using refrigerants of group 2, as provided in art.13, cap.1, section B of Directive 2014/68/UE with reference to the Regulation (CE). With HNBR gaskets (on request) may be used with R290 refrigerant fluids.

The main components of the solenoid valves in the 11000 series are:

• Body made of brass EN12165 CW617N or EN12164-CW614N
• Sleeve made of brass EN12164 CW614N
• Cores made of ferromagnetic steel
• Springs made of steel AISI 302
• Coil H class with anti-humidity gaskets
• Brass pipe EN12735-1-Cu-DHP
• Neoprene/HNBR sealing O-ring
