Category: DIRECT ACTION SOLENOID VALVES
Ways: 2/2 N.C.
Notes:
Designed to meet the most demanding requirements of
professional food & beverage applications, the 08600L series
solenoid valves offer a combination of mechanical strength, long-lasting
durability, and full compatibility with food-grade fluids.
The body
in forged brass EN12165-CW617N (OT57), the insert in AISI 303
stainless steel, and the sleeve in AISI 304L stainless steel laser
welded to the fixed core ensure high structural performance even in harsh
environments or intensive duty cycles.
The sealing system features a DN synthetic ruby gasket,
a material that provides exceptional resistance to wear, chemical
agents, and aging, significantly extending the valve’s service life
and reducing maintenance needs. The sleeve-to-body sealing is ensured by an OLAB-certified
food-grade FKM (Viton) O-ring, compliant with the strictest international
safety standards for food contact.
The direct acting configuration allows operation even
in the absence of differential pressure, ensuring quick response
and safe operation under any system condition, including low-pressure
circuits.
The 30 mm Ø14 coil, class H (180°C) and UL and
VDE certified, guarantees high performance and full compliance with
professional operating standards.
With a maximum operating pressure (PS) of 40 bar (580
psi) and a temperature range (TS) from -15°C to +160°C (+5°F to +320°F),
this series is a high-performance solution compliant with MOCA
and NSF regulations, ideal for systems requiring maximum reliability,
food safety, and long-term endurance.
Technical features:
Food & Beverage
SUITABLE
FOR FOOD CONTACT THANKS TO MAXIMUM COMPATIBILITY WITH FOOD-GRADE FLUIDS
Specifically designed to ensure full compliance with food applications, these
solenoid valves use MOCA- and NSF-certified materials and components that meet
international food safety standards, delivering maximum reliability in
hydraulic circuits for the food & beverage industry.
RUBY
SEAL FOR OUTSTANDING DURABILITY AND LONG-LASTING PERFORMANCE
The special synthetic ruby sealing gasket offers superior resistance to wear
and chemical agents, ensuring a long service life even under intense and
continuous operating conditions, while minimizing the need for maintenance.
STAINLESS
STEEL INSERT FOR STRUCTURAL RELIABILITY AND LONG-LASTING STRENGTH
The internal stainless steel insert ensures mechanical robustness, dimensional
stability, and corrosion resistance, providing long-term durability and
reliability even in harsh environments.
DIRECT
ACTING WITHOUT MINIMUM PRESSURE REQUIREMENT
The direct action configuration enables operation even in the absence of
differential pressure, ensuring fast and safe opening in any system condition,
including low-pressure circuits.
THE
IDEAL SOLUTION FOR HIGH-PERFORMANCE PROFESSIONAL APPLICATIONS
Engineered for continuous use in professional systems, these solenoid valves
deliver high performance thanks to the quality of their materials and the UL
and VDE certified coils, ensuring safety and compliance with the most demanding
international standards.
